Apache Flume Sink

Apache Flume Sink is the component of the Flume agent that is used to consume the data from the channel and send them to the destination system. Flume Sink is associated with a unique name that is used to bifurcate the configuration and working namespaces.

Apache Flume provides different types of the sink as mentioned below.

HDFS Sink
Hive Sink
Logger Sink
Avro Sink
Thrift Sink
IRC Sink
File Roll Sink
Null Sink
HBase Sink
MorphlineSolr Sink
ElasticSearch Sink
Kite Dataset Sink
HTTP Sink
Custom Sink

Let us see each Flume Sink in detail.

1. HDFS Sink

Apache Flume HDFS sink is used to move events from the channel to the Hadoop distributed file system. It also supports text and sequence-based files.

If we are using Apache Flume HDFS Sink in that case Apache Hadoop should be installed so that Flume can communicate with the Hadoop cluster using Hadoop JARs.

We need to note here that the version of Hadoop that supports the sync() call is a must.

Example for the Apache Flume HDFS Sink.



    agentone.channels = channelone
    agentone.sinks = k1
    agentone.sinks.k1.type = hdfs
    agentone.sinks.k1.channel = channelone
    agentone.sinks.k1.hdfs.path = /flume/events/%y-%m-%d/%H%M/%S
    agentone.sinks.k1.hdfs.filePrefix = events-
    agentone.sinks.k1.hdfs.round = true
    agentone.sinks.k1.hdfs.roundValue = 10
    agentone.sinks.k1.hdfs.roundUnit = minute

2. Hive Sink

Apache Flume Hive Sink streams delimited text or JSON events directly into a Hive table or partition. Once events are committed to the Hive table post that it becomes visible to Hive queries.

Apache Hive partitions can be pre-created or Flume will create them before streaming data and the fields for stream data will be mapped with matching columns in the Hive table.

Example for Apache Hive table.



    create table web_data ( id int , msg string )
    partitioned by (continent_data string, country_code string, time string)
    clustered by (id) into 5 buckets
    stored as orc;

Example for Apache Flume Hive Sink.



    agentone.channels = channelone
    agentone.channels.channelone.type = memory
    agentone.sinks = k1
    agentone.sinks.k1.type = hive
    agentone.sinks.k1.channel = channelone
    agentone.sinks.k1.hive.metastore = thrift://127.0.0.1:9083
    agentone.sinks.k1.hive.database = logsdb
    agentone.sinks.k1.hive.table = weblogs
    agentone.sinks.k1.hive.partition = asia,%{country},%y-%m-%d-%H-%M
    agentone.sinks.k1.useLocalTimeStamp = false
    agentone.sinks.k1.round = true
    agentone.sinks.k1.roundValue = 10
    agentone.sinks.k1.roundUnit = minute
    agentone.sinks.k1.serializer = DELIMITED
    agentone.sinks.k1.serializer.delimiter = "\t"
    agentone.sinks.k1.serializer.serdeSeparator = '\t'
    agentone.sinks.k1.serializer.fieldnames =id,,msg

3. Logger Sink

Apache Flume Logger Sink is basically used for testing/debugging purpose and will not require any extra configuration.

Example for Apache Flume Logger Sink.



    agentone.channels = channelone
    agentone.sinks = k1
    agentone.sinks.k1.type = logger
    agentone.sinks.k1.channel = channelone

4. Avro Sink

Apache Flume Avro sink gets the stream in the form of batches and sent them to the configured hostname/port pair.

Example for Apache Flume Avro Sink.



    agentone.channels = channelone
    agentone.sinks = k1
    agentone.sinks.k1.type = avro
    agentone.sinks.k1.channel = channelone
    agentone.sinks.k1.hostname = 10.10.10.10
    agentone.sinks.k1.port = 4545

5. Thrift Sink

Apache Flume Thrift Sink gets the flume events in batches from the channel and converted them into Thrift events and sent to the configured hostname/port pair.

Example for Apache Flume Thrift Sink.



    agentone.channels = channelone
    agentone.sinks = k1
    agentone.sinks.k1.type = thrift
    agentone.sinks.k1.channel = channelone
    agentone.sinks.k1.hostname = 10.10.10.10
    agentone.sinks.k1.port = 4545

6. IRC Sink

Apache Flume TIRC Sink gets the messages from the channel and gives them to configured IRC destination systems.

Example for Apache Flume IRC Sink.



    agentone.channels = channelone
    agentone.sinks = k1
    agentone.sinks.k1.type = irc
    agentone.sinks.k1.channel = channelone
    agentone.sinks.k1.hostname = irc.yourdomain.com
    agentone.sinks.k1.nick = flume
    agentone.sinks.k1.chan = #flume

7. File Roll Sink

Apache Flume File Roll Sink gets the steams from the channel and stores events on the local file system.

Example for Apache Flume File Roll Sink.



    agentone.channels = channelone
    agentone.sinks = k1
    agentone.sinks.k1.type = file_roll
    agentone.sinks.k1.channel = channelone
    agentone.sinks.k1.sink.directory = /var/log/flume

8. Null Sink

Apache Flume Null Sink cancels all events that are received from the channel.

Example for Apache Flume Null Sink.



    agentone.channels = channelone
    agentone.sinks = k1
    agentone.sinks.k1.type = null
    agentone.sinks.k1.channel = channelone

9. HBase Sink

Apache Flume HBase sink check the configuration file of the hbase-site.xml and then write data into the HBase database.

The following two types of serializers are provided with Apache Flume for convenience.

SimpleHbaseEventSerializer: This serializer is primarily an example implementation that is used to write the event body as-is to HBase, and optionally increments a column in Hbase.
RegexHbaseEventSerializer: This serializer breaks the event body based on the given regex and writes each part into different columns.

Example for HBase Sink.



    agentone.channels = channelone
    agentone.sinks = k1
    agentone.sinks.k1.type = null
    agentone.sinks.k1.channel = channelone

HBase supports two types of sink models, HBase2Sink and AsyncHBase Sink.

Let us see each HBase sink model in detail.

9.1 HBase2 Sink

HBase2 Sink is similar to HBase Sink for HBase version 2. The only difference is the hbase2 tag in the sink type and the package/class names. The type is the FQCN: org.apache.flume.sink.hbase2.HBase2Sink.

Example for HBase2 Sink.



    agentone.channels = channelone
    agentone.sinks = k1
    agentone.sinks.k1.type = hbase2
    agentone.sinks.k1.table = foo_table
    agentone.sinks.k1.columnFamily = bar_cf
    agentone.sinks.k1.serializer = org.apache.flume.sink.hbase2.RegexHBase2EventSerializer
    agentone.sinks.k1.channel = channelone

9.2 AsyncHBase Sink

AsyncHBase Sink uses the Asynchbase API to write to HBase. AsyncHBase sink provides the same consistency guarantees as HBase, which is currently row-wise atomicity.

Example for AsyncHBase Sink.



    agentone.channels = channelone
    agentone.sinks = k1
    agentone.sinks.k1.type = asynchbase
    agentone.sinks.k1.table = foo_table
    agentone.sinks.k1.columnFamily = bar_cf
    agentone.sinks.k1.serializer = org.apache.flume.sink.hbase.SimpleAsyncHbaseEventSerializer
    agentone.sinks.k1.channel = channelone

10. MorphlineSolr Sink

Apache Flume MorphlineSolr Sink is stream data into HDFS (via the HdfsSink) and concurrently extract, transform and load the same data into Solr (via MorphlineSolr Sink).

We can configure ETL functionality by using a morphine configuration file that defines a chain of transformation commands that pipe event records from one command to another. The JAR of Solr and morphine should be placed under the lib directory of Apache Flume.

Example for the Apache Flume MorphlineSolr Sink.



    agentone.channels = channelone
    agentone.sinks = k1
    agentone.sinks.k1.type = org.apache.flume.sink.solr.morphline.MorphlineSolrSink
    agentone.sinks.k1.channel = channelone
    agentone.sinks.k1.morphlineFile = /etc/flume-ng/conf/morphline.conf
    # agentone.sinks.k1.morphlineId = morphline1
    # agentone.sinks.k1.batchSize = 1000
    # agentone.sinks.k1.batchDurationMillis = 1000

11. ElasticSearch Sink

Apache Flume ElasticSearch Sink writes data to an elastic search cluster at midnight UTC.

Example for the Apache Flume ElasticSearch Sink.



    agentone.channels = channelone
    agentone.sinks = k1
    agentone.sinks.k1.type = elasticsearch
    agentone.sinks.k1.hostNames = 127.0.0.1:9200,127.0.0.2:9300
    agentone.sinks.k1.indexName = foo_index
    agentone.sinks.k1.indexType = bar_type
    agentone.sinks.k1.clusterName = foobar_cluster
    agentone.sinks.k1.batchSize = 500
    agentone.sinks.k1.ttl = 5d
    agentone.sinks.k1.serializer = org.apache.flume.sink.elasticsearch.ElasticSearchDynamicSerializer
    agentone.sinks.k1.channel = channelone

12. Kite Dataset Sink

Apache FlumeKite Dataset is an experimental sink that writes events to a Kite Dataset.

13. HTTP Sink

Apache Flume HTTP Sink takes an event from the channel and sends those events to a remote service using an HTTP POST request. The content of the event is sent as the POST body. In case there is an error then a backoff signal is raised and events are not consumed from the channel.

Example for Apache Flume HTTP Sink.



    agentone.channels = channelone
    agentone.sinks = k1
    agentone.sinks.k1.type = http
    agentone.sinks.k1.channel = channelone
    agentone.sinks.k1.endpoint = http://localhost:8080/someuri
    agentone.sinks.k1.connectTimeout = 2000
    agentone.sinks.k1.requestTimeout = 2000
    agentone.sinks.k1.acceptHeader = application/json
    agentone.sinks.k1.contentTypeHeader = application/json
    agentone.sinks.k1.defaultBackoff = true
    agentone.sinks.k1.defaultRollback = true
    agentone.sinks.k1.defaultIncrementMetrics = false
    agentone.sinks.k1.backoff.4XX = false
    agentone.sinks.k1.rollback.4XX = false
    agentone.sinks.k1.incrementMetrics.4XX = true
    agentone.sinks.k1.backoff.200 = false
    agentone.sinks.k1.rollback.200 = false
    agentone.sinks.k1.incrementMetrics.200 = true

14. Custom Sink

Apache Flume Custom Sink is the user’s own implementation of the Sink interface. After starting Flume Agent, a custom sink’s class and its dependencies must be included in the agent’s classpath.

Example for Custom Sink.



    agentone.channels = channelone
    agentone.sinks = k1
    agentone.sinks.k1.type = org.example.MySink
    agentone.sinks.k1.channel = channelone
